Propane Reserve Systems

Tired of having your forklift or propane equipment
run out of propane at the wrong time?

WE HAVE THE SOLUTION

PATENT PENDING

Propane Reserve Systems | 2016 | Web Design by Mustang Media, Inc.

THE SYSTEM

The Propane Reserve System kit contains the following:

  • Propane bottle (empty)
  • Mounting hardware and bracket
  • Fittings and 30" hose (if you need a different length, please note in comment box below after ordering)
  • Spray bottle for checking for leaks
  • Instructions on how to use the system

PROPANE RESERVE SYSTEMS

Are you tired of having your forklift or propane equipment run out of propane at the wrong time? I have found the solution by making a reserve tank that mounts to your equipment and ties into your existing system.  How it works is you have a small extra tank that gets mounted to your equipment in a safe place then when you run out of propane you simply turn off your big tank and open the reserve tank.

You then restart your machine and finish your job or return to where your extra full tanks are to put on a new tank. No more down time or dead forklifts. No more being stranded and having to walk to get a new tank. No more having to stop the assembly line because the forklift is in the way or stopping traffic because it ran out of propane while you were unloading a truck in the street. Will fit any forklift Catapiller, Toyota, Komatsu, Nissan, Hyster, Clark, Yale, Daewoo and many more.

HOW IT WORKS

ORDER HERE

INSTRUCTIONS

1. Attaching the reserve tank brackets:

Using the brackets and bolts provided, place the bracket on one side of the roll bar and the flat iron on the other side sandwiching the roll bar in between.  Make sure the bracket is in a safe place so that it does not block your sight and will not get hit by anything.  Remember to keep the bolts as close to the post as possible.

2. Installing the "T" fitting:

Follow the original hose from the main tank to the fitting with the pop off valve.  If you cannot find this fitting, contact your local dealer to ensure that you are hooking up to the right place.  When you find the “Y” fitting with the pop off valve, attach the “T” fitting.  Take off the hose from the main tank and the pop off valve and put on the double female flange fitting.  Then connect the “T to the other end of the female fitting.  Note before and after pictures.

3. Attaching the hoses:

Attach existing hose to one side of the “T” fitting.  Attach new hose provided to the other side of the “T” fitting.  (This hose will attach to the reserve tank).  Follow all local regulations on connecting propane fittings.

4. Take the reserve tank to be filled by a certified propane filler.

5. Final installation and checking for leaks:

Install the reserve tank in the bracket and hook up the hose and make sure it is secure.  Then open the valve and check for leaks by spraying soapy water on ALL fittings.  If soapy bubbles are present, THERE IS A LEAK: DO NOT USE THE SYSTEM.  Close the valve and re-tighten leaking fittings immediately then open valve and check for leaks again.



If no leaks can be found and the reserve tank is mounted in a sturdy, secure, and safe place, the system is ready for use.

ORDER

$900



If you have any questions, please send me an email and I will be happy to answer them for you. Shipping is available anywhere in the United States except California, Hawaii and Alaska. Patent pending.



When purchasing, choose the number of units you'd like to purchase in the drop down. Once you have clicked "Add to Cart", you will be able to change the quantity but the multiple unit discount may not apply. Also, please tell use how you heard about us!





One unit contains the following:

Propane bottle (empty)

Mounting hardware and bracket

Fittings and 30" hose
(please note a different length you'd like in comment box below after ordering)

Spray bottle for checking for leaks

Instructions on how to use the system.



To order 1 to 10 units:

Multiple Unit Discount
How did you hear about us?

To order 11 or more units:

Multiple Unit Discount
How did you hear about us?
